Lowdoller 16 Tooth Driveshaft Reluctor Ring RPM Collar 1.750″ ID

Add a driveshaft speed signal to your data logger or ECU with this Lowdoller 16 tooth reluctor ring, sized for a 1.750″ inside diameter.

The two-piece split collar clamps straight onto the driveshaft or pinion yoke, so there’s no need to pull anything apart to fit it. The redesigned collar is lighter than the previous version.

Specifications

• Inside diameter: 1.750″
• Outside diameter: 3.859″
• Teeth: 16
• Thickness: 0.375″
• Material: steel (ferrous)
• 2-piece split collar design
• Retaining screws: 8-32 UNC, 9/64″ hex key

Fitment

• Ford 9″ and 8.8″
• Dana 60
• GM 12 bolt
• Other traditional style diffs

Works with Lowdoller hall effect speed sensors and most other common speed sensors designed for toothed wheels. Measure your driveshaft or yoke diameter before ordering to choose the right size.

Manufactured by Lowdoller Motorsports. For off-road and competition use only.
